Low Cost Wheel Loader

Operating weight: 1,460 kg.
Fully electric drive ensures clean, zero-emission operation.
Comes standard with a 60V power system and 150Ah battery.
Features a durable, maintenance-free battery unit.
Equipped with 23×8.5-12 tires for stable handling.
Powered by a robust 2.5 kW AC motor.
4-wheel drive with a 45° steering capability.

Contact Now E-Mail Telephone WhatsApp

Product Details

The new K800E electric loader from KIMA features fast motor response, precise control, and high efficiency. Despite its compact size, it provides strong performance, making it ideal for tight spaces such as urban construction sites, warehouses, docks, and other areas with limited room.

Battery Powered Construction Equipment

Product advantages

Eco-Friendly
The K800E produces zero exhaust emissions, making it fully environmentally friendly and compliant with modern standards for energy saving and emission reduction.

Quiet Operation
With its electric drive system, the K800E operates quietly, minimizing noise at the worksite and reducing strain on the operator.

Low Maintenance Costs
Electricity costs are generally more stable than fuel, and the simple design of the electric drive system requires less maintenance. There’s no need for routine oil or filter changes, lowering overall upkeep expenses.

Responsive & Flexible
The electric drive provides quick response and smooth control, allowing the K800E to efficiently handle various tasks and adapt to challenging work conditions.

Versatile Attachments
The K800E can serve as a multifunctional machine, offering a wide range of attachments to meet diverse operational needs.

Product parameters

DIMENSIONS
Max. Lifting Height	1798 mm
Max. Dumping Height	1217 mm
Max. Dumping Reach	593 mm
Dumping Angle	43°
Overall Length	3052 mm
Overall Width	1052 mm
Overall Height	2239 mm
Wheel Base	1425 mm
Min. Ground Clearance	198 mm
Max. Turning Radius	2982 mm
Max. Turning angle	45°
PERFORMANCE
Max. Speed	15 km/h
Max. Lifting Weight	800 kg
Max. Excavation Force	10 KN
Max. Grade Ability	25°
Net Weight	1460 kg
Battery Type	6 - EVEJ - 150
Battery Capacity	150 Ah
Voltage	60 V
No. of Batteries	5
Working Hours	4 - 5 h
Charging Hours	8 h
Motor Type	IM150802S
Power	2500 W
Operating Pressure	20Mpa
Flow Rate	1580kg
Type	23*8.5 - 12
Tank Capacity	15.2L
Service Brake	Drum Brake
Parking Brake	Drum Brake
Bucket Capacity	0.15 m³
